CONSORT diagram layers for ggplot2 — geom

geom_consort() draws the boxes, arrows, and lines of a ggconsort object created with consort_box_add(), consort_arrow_add(), and consort_line_add(). It measures the rendered size of each box at draw time, so boxes are centered on their (x, y) coordinates and arrows start and end exactly at box edges, whatever the device size. geom_consort_arrow() and geom_consort_box() are the legacy component layers, which anchor arrows at box centers and shift box text by its justification; they remain available for diagrams that depend on that behavior. geom_consort_line() draws a standalone line segment with the same styling as the diagram lines.

Usage

geom_consort(
  label_color = "black",
  label_size = 11,
  label_height = 1,
  family = "",
  fill = "white",
  box_color = "black",
  linewidth = 0.25,
  box_r = 0,
  box_padding = 0.25,
  arrow_length = 2,
  row_gap = NULL,
  equal_columns = FALSE
)

geom_consort_arrow(...)

geom_consort_box(label_color = "black", label_size = 11, label_height = 1, ...)

geom_consort_line(x, xend, y, yend, ...)

Arguments

label_color: Color of the box label text.
label_size: Size of the box label text, in points.
label_height: Line height of the box label text.
family: Font family of the box label text. The default ("") uses the device default.
fill: Fill color of the boxes. Individual boxes can override this with the fill argument of consort_box_add().
box_color: Color of the box borders.
linewidth: Width of the box borders; arrows and lines are drawn slightly lighter, in proportion.
box_r: Corner radius of the boxes, in lines. The default 0 draws square corners, as in the official CONSORT and PRISMA templates.
box_padding: Padding between a box's text and its border, in lines.
arrow_length: Length of the arrow heads, in millimeters.
row_gap: In a row/column layout, the vertical gap between rows, in lines. The default (NULL) equalizes the gaps to fill the panel, capped at 2 lines so the diagram stays compact on large devices.
equal_columns: In a row/column layout, should all boxes in a column be drawn at the width of the column's widest box? The official CONSORT and PRISMA templates use uniform-width boxes.
...: For geom_consort_box(), additional arguments passed to ggtext::geom_richtext(). Ignored by geom_consort_arrow().
x, xend, y, yend: Coordinates of the line segment drawn by geom_consort_line().

Value

A ggplot2 layer or list of layers that can be added to a plot.

Examples

cohorts <- trial_data |>
  cohort_start("Assessed for eligibility") |>
  cohort_define(
    randomized = .full |> dplyr::filter(declined != 1),
    excluded = dplyr::anti_join(.full, randomized, by = "id")
  ) |>
  cohort_label(
    randomized = "Randomized",
    excluded = "Declined to participate"
  )

consort <- cohorts |>
  consort_box_add("full", row = 1, label = cohort_count_adorn(cohorts, .full)) |>
  consort_box_add("excluded", row = 2, col = "side") |>
  consort_box_add("randomized", row = 3) |>
  consort_arrow_add(start = "full", end = "randomized") |>
  consort_arrow_add(start = "full", end = "excluded")

library(ggplot2)
ggplot(consort) +
  geom_consort() +
  theme_consort()
