Add boxes, arrows, lines, and stage badges to a CONSORT diagram

Source: R/consort_arrow_add.R, R/consort_box_add.R, R/consort_line_add.R
consort_box_add.Rd

These functions add the visual elements of a CONSORT diagram to a ggconsort_cohort object, converting it to a ggconsort object that can be plotted with ggplot2::ggplot() and geom_consort().

Usage

consort_arrow_add(
  .data,
  start = NA,
  start_side = NA,
  end = NA,
  end_side = NA,
  start_x = NA,
  start_y = NA,
  end_x = NA,
  end_y = NA
)

consort_box_add(
  .data,
  name,
  x = NULL,
  y = NULL,
  label = NULL,
  hjust = NULL,
  vjust = NULL,
  row = NULL,
  col = NULL,
  fill = NULL,
  color = NULL,
  text_color = NULL
)

consort_stage_add(
  .data,
  label,
  row,
  col = "margin",
  fill = "#9bc0fc",
  angle = 0
)

consort_line_add(
  .data,
  start = NA,
  start_side = NA,
  end = NA,
  end_side = NA,
  start_x = NA,
  start_y = NA,
  end_x = NA,
  end_y = NA
)

Arguments

.data

A ggconsort_cohort object, or a ggconsort object returned by a previous consort_*_add() call.

start, end

Names of the boxes where the arrow or line starts and ends. In a row/column layout, end may be a vector of names to draw a T-split from start into several boxes.

start_side, end_side

The side of the box ("left", "right", "top", or "bottom") that the arrow or line leaves from or points to. Optional: by default the sides follow from the relative positions of the two boxes.

start_x, start_y, end_x, end_y

Explicit coordinates for the start and end of the arrow or line, as an alternative to naming boxes with start/end. Not available in row/column layouts.

name

A character name identifying the box, used to connect arrows and lines to the box.

x, y

Coordinates of the box. Omit them (and set row/col) to use the row/column layout instead.

label

Text displayed in the box. Interpreted as markdown/HTML by ggtext/gridtext, so labels may contain formatting such as <br> or **bold**. When name matches a cohort defined with cohort_define(), label may be omitted: the box is labeled automatically with the cohort's label and count, as by cohort_count_adorn(). cohort_count_bullets() is a convenient way to build multi-line labels such as exclusion boxes.

hjust, vjust

Optional numeric justification of the box relative to (x, y), in [0, 1]. By default boxes are centered on their coordinates (hjust = vjust = 0.5). E.g. hjust = 0 places the box's left edge at x. Ignored in row/column layouts.

row, col

Grid position of the box or stage badge (see the "Row/column layout" section). For consort_stage_add(), row and col may be length-2 vectors to center the badge across a span of rows or columns (e.g. col = c("main", "side") for a header bar spanning the diagram).

fill

For consort_box_add(), an optional fill color for this box, overriding the geom_consort() fill. For consort_stage_add(), the fill color of the stage badge.

color, text_color

Optional border and text colors for this box, overriding the geom_consort() box_color and label_color.

angle

Rotation of the stage badge text, in degrees (e.g. 90 for the vertical labels of a PRISMA diagram).

Value

A ggconsort object.

Details

  • consort_box_add() adds a text box, either at explicit (x, y) coordinates or at a (row, col) grid position.

  • consort_arrow_add() adds an arrow between two boxes (referenced by name) or between explicit coordinates.

  • consort_line_add() adds a line without an arrow head, with the same interface as consort_arrow_add().

  • consort_stage_add() adds a stage badge (e.g. "Allocation") to a row/column layout.

Row/column layout

Instead of picking coordinates by hand, boxes can declare a grid position with row and col. Rows count from 1 at the top. col is "main" (the central spine, column 0), "side" (column 1, right of the spine), "left" (column -1), or any number. Stage badges may also use "margin" (their default), which resolves to one column left of the leftmost box so badges sit in the margin, as in the official CONSORT and PRISMA templates. At draw time ggconsort measures every box on the open graphics device and lays the grid out to fill the plot: row gaps are equalized (capped so large devices stay compact), columns are spread so boxes never overlap, and nothing is clipped, whatever the device size.

In a row/column layout, arrows need only start and end names:

  • boxes in the same column are connected vertically,

  • boxes in the same row are connected horizontally,

  • a box in another column and row is reached by a horizontal branch off the start box's vertical spine, at the height of the target box, and

  • a vector end (e.g. end = c("arm_a", "arm_b")) draws the classic T-split: one drop from the start box, a crossbar, and an arrow down into each arm.

A diagram must use either coordinates or rows/columns, not a mixture.

Examples

cohorts <- trial_data |>
  cohort_start("Assessed for eligibility") |>
  cohort_define(
    randomized = .full |> dplyr::filter(declined != 1),
    excluded = dplyr::anti_join(.full, randomized, by = "id")
  ) |>
  cohort_label(
    randomized = "Randomized",
    excluded = "Declined to participate"
  )

# row/column layout: no coordinates, spacing computed at draw time.
# Boxes named after a cohort are labeled automatically with its count.
consort <- cohorts |>
  consort_box_add("full", row = 1, col = "main",
    label = cohort_count_adorn(cohorts, .full)) |>
  consort_box_add("excluded", row = 2, col = "side") |>
  consort_box_add("randomized", row = 3, col = "main") |>
  consort_arrow_add(start = "full", end = "randomized") |>
  consort_arrow_add(start = "full", end = "excluded") |>
  # a stage badge in the margin, spanning rows 1 to 3
  consort_stage_add("Enrollment", row = c(1, 3))

library(ggplot2)
ggplot(consort) +
  geom_consort() +
  theme_consort()
